5. Slowly turning the gas pressure controller (cylinder check valve), make
sure that no gas leaks are present. For that:
- Lubricate all joints with soapy water. Gas leaks cause formation of bubbles
in permeable places.
- NEVER USE MATCHES OR LIGHTERS for gas leak checks.
If you find a gas leak, shut gas and contact your dealer or manufacturer's
service center.
6. Install the gas cylinder to the dedicated place inside the appliance and
secure with the clamp.
7. Carry the heater to the supposed place of operation observing the rules
and precautions described in Section 2 of this Instruction Manual.
8. The appliance is ready for work.
WARNING!
All gas joints and pipes should be absolutely tight to exclude even slightest
gas leaks. Never use matches, lighters, and other sources of open flame for
leak checks of joints. Use soapy water.
It is prohibited to use the gas-fired heater in flats of high-rise buildings,
bedrooms, bathrooms, and cellars.
Upon first ignition, it is recommended to preliminarily switch the heater on
outdoors, after which it can be used indoors.
The room, where the gas-fired heater is used, should be equipped with
natural ventilation.
Do not use the heater during sleep.
Always use only certified, recommended by the manufacturer, and properly
rated hoses/pressure reducers for connection of the appliance.
Always use only the gas type indicated by the manufacturer.
During operation of the appliance, watch that the gas cylinder is always
strictly vertical. Use of the cylinder in any other position may result in
occurrence of an emergency situation, breakdown of the appliance, and
infliction of a significant damage to you and/or your property.
It is prohibited to move or anyhow cover the heater during operation, as well
as after shutdown, if the heater is still hot.
The heater should be placed for operation so that its face plate is directed
towards the room center. At that, distances to walls or other objects on sides
and behind the appliance should be at least 1 m.
Connection to electric mains (for TGH 4200 O2 model)
1. The heater is designed for connection to the single-phase 220 VAC electric mains
equipped with a grounding loop.
2. Before connection, make sure that specifications of the electric mains at the
connection point meet the parameters indicated on the appliance nameplate.
3. Upon connection of the appliance to the electric mains, it is necessary to observe the
effective rules of electric safety.
4. The electric socket should be properly earthed. The socket should be designed for
rated current at least 10A. The electric socket and plug should be always dry to avoid
current leaks. Regularly check that the electric plug is tightly inserted into the socket as
follows: a) insert the electric plug into the socket; b) in half an hour of operation, switch
the heater off and remove the plug from the socket; c) check the plug by hand, whether it
is hot. If the plug has temperature over 50° , replace the socket with another one to
avoid damage, accidents, or occurrence of fire as a result of poor electric contact. The
socket should be replaced by a specialist.
ATTENTION!
The electric socket should be designed for rated current at least 10A and
an electric cable with wires at least 3x1.5 mm2 in sections (for copper)
7. Control of ceramic gas-fired heater
Ventilation
During operation, the gas-fired heater burns oxygen contained in air and
emits carbon dioxide (CO2).
It is important to remember that operation of the gas-fired ceramic heater is
permitted only in well ventilated rooms. This allows keeping the necessary
concentration of oxygen in air and removing combustion products.
Operation of the heater in closed and poorly ventilated rooms may create an
asphyxiating atmosphere and cause a lack of oxygen. If the oxygen
concentration decreases below 18%, the ODS system (oxygen detector)
activates and switches the heater off. In this case it is necessary to ventilate the
room before restarting the heating mode.
ATTENTION!
Do not start the gas-fired ceramic heater in rooms having volume less
3 than 84 m .
2 The minimum area of a vent should be at least 105 cm .
3 Necessary air exchange 10m / hour der 1 kW of thermal power heater.
12 www.timberk.com 5 www.timberk.com gas heater
