Specifications
DVD Player/Outputs/Supplied Accessories
DVD Player
Power supply 110 V - 240 V AC, 50/60 Hz
Power Consumption 12W (standby: <3W)
Net weight 1.49 kg
External dismensions 430 X 43 X 209 mm (W/H/D)
Signal System PAL, NTSC
Laser Semiconductor laser, wavelength 650/780 nm
Frequency range DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz
Signal-to-noise ratio More than 90 dB
Audio dynamic range More than 80 dB
Harmonic distortion More than 65 dB
Wow and flutter Below measurable level [(less than ＋ 0.001 % ( W.PEAK )]
Operating conditions Temperature : 5 O C to 35 O C Operation status :Horizontal
Outputs
Video output 1.0 V ( p-p ) , 75 Ω negative sync., pin jack x 1
Video output (SCART) 1.0 V ( p-p ) , 75 Ω, SCART socket x 1
Component video output (Y) 1.0 V (p-p), 75 Ω negative sync., pin jack x 1
(P B )/(P R ) 700 mV (p-p), 75 Ω, pin jack x 2
Audio output (SCART) 2.0 V (rms), 680 Ω, SCART socket x 1
Audio output ( COAXIAL DIGITAL ) 0.5 V (p-p) 75 Ω pin jack x 1
Audio output (ANALOG)
2.0 V (rms), 680 Ω, pin jacks (L/R) x 1
Supplied Accessories
Audio/Video cable
OPEN/CLOSE DISPLAY
1 2 3
6 5 4
7 8 9
+10 0 T-SEARCH
SETUP MENU
RETURN TITLE
OK
F.R F.F PREV NEXT
STEP STOP PLAY/PAUSE
REPEAT A-B
SUBTITLE ANGLE AUDIO ZOOM
SLOW
PROG RANDOM
S E -R 0268
ON/STANDBY
CLEAR
Remote control(SE-R0301)
Batteries(AAA)
OPEN/CLOSE DISPLAY
1 2 3
6 5 4
7 8 9
+10 0 T-SEARCH
SETUP MENU
RETURN TITLE
OK
F.R F.F PREV NEXT
STEP STOP PLAY/PAUSE
REPEAT A-B
SUBTITLE ANGLE AUDIO ZOOM
SLOW
PROG RANDOM
S E -R 0268
ON/STANDBY
CLEAR
 The model complies with the above specifications.
 Designs and specifications are subject to change without notice.
 This model may not be compatible with features and /or specifications that may be added in the future.
