60 GW28-009_v01
How to use the iron lock
Iron Lock button have the three positions, Move Iron Lock Button from Up
to Bottom (or) Bottom to Up.
Up position – remove the iron without the cord:
Put the iron to the stand.
Move the button on up position .
You can remove the iron without the cord.
Middle position – locking:
Put the iron to the stand.
Move the button on middle position .
The iron is locked with the stand.
Bottom position – remove the iron with the cord:
Put the iron to the stand.
Move the button on bottom position .
You can remove the iron with the cord.
How to fill the water
Disconnect the iron from mains supply outlet. –
Remove the iron from the Stand as –
described “How to Use Iron Lock”
Release the – Water Inlet Cover (2).
Fill water through the water inlet hole. –
Fill up to the ‘ – MAX’ level marked on the
side of water tank.
Close the – Water Inlet Cover (2).
Note:
For best result, it is advisable to use demineralised water or distilled
water. Do not use chemically descaled water or any other liquids.
Preparation for operation – first ironing
Remove any protective films or sticker from the – soleplate (12) and the
cabinet, if any.
Unwind and straighten the – power cord (11).
Fill the iron as described in “How to fill water”. –
Lock the iron with stand as described in “How to Use Iron Lock”. –
Connect the iron to a suitable mains supply outlet. –
Turn the – Temperature Dial (9) in clockwise direction to ●●● position
– control light (6) glows.
Control light goes off when the required temperature is reached. –
Move the – Steam Control Knob (3) to position.
Steam starts coming out from the holes in the sole plate after putting –
the iron in horizontal position and after Burst of steam knob (4)
Remove the iron from the stand as described in “How to Use Iron –
Lock”.
Begin first time ironing with an old towel. –
When the water tank is empty and there is no more steam produced; the –
preparation work is completed. The iron is now ready for proper use.
After operation
Move the – Temperature Dial (9) in anti-clockwise direction to „MIN”;
the iron is switched off.
Move the – Steam Control Knob (3) to position.
Disconnect the iron from mains supply outlet. –
When the iron gets cool completely, store it vertically in a safe place. –
Spraying
This function can be used any time and is not affect any setting. –
Fill the water tank as described in How to Fill Water. –
Aim the – nozzle (1) to the garment.
Press the – Spray Button (5).
It may be necessary to press the spray button a few times to start this –
function.
Dry ironing – Always follow the garment manufacturer’s ironing
instructions mentioned at the garment label.
Unwind and straighten the – power cord (11).
Fill the iron as described in “How to fill water”. –
Lock the iron with stand as described in “How to Use Iron Lock”. –
Move the – Steam Control Knob (3) to position.
Connect the iron to a suitable mains supply outlet. –
Turn the – Temperature Dial (9) in clockwise direction to; set ●, ●● or
●●● position.
