Do not leave the appliance unattended when it is connected to a mains
–
supply outlet or it is hot.
The iron is not to be used if it has been dropped, if there are visible
–
signs of damage or if it is leaking.
If you do not use the iron, even for short time, switch it off, turning Tem-
–
perature Dial in anti-clockwise direction to „
MIN”.
If you do not use the iron, even for short time, switch the steam func-
–
tion off, setting the knob on position.
Never iron and clothes or fabrics that are being worn by human or pets.
–
Never direct the steam to human or pets.
–
Use self-cleaning function at least once a month.
–
Hints for ironing
1. Sort out the articles to be ironed according to the type of fabric. This will
minimize the frequency of temperature adjustment for different garments.
2. Test ironing a small area on the backside or inside the garment if you
are unsure about the type of fabric. Start with a low temperature and
increase gradually.
3. Wait for about three minutes before ironing heat sensitive fabrics. Tem-
perature adjustment needs certain time to reach the required level no
matter it is higher or lower.
4. Delicate fabrics such as silk, wool, velour, etc. are best ironed with an
ironing cloth to prevent shine marks.
5. You may need a few times of press to activate the spray, burst and
vertically burst function.
6. Read the garment labels and follow the manufacturer’s ironing
instructions which are often shown by symbols similar to the fol-
lowing:
Temperature settings
○ Acetate
○ Elastics
○ Polyamide
○ Polypropylene
○ Cupro
○ Triacetate
○ Polyester
○ Viscose
○ Proteins
○ Wool
○ Silk
○ Cotton
○ Linen
Technical data
The iron technical parameters are included at the name plate. The iron is
I class appliance, equipped with supplying cord and plug with grounding.
ZELMER iron meets the requirements of effective standards.
The appliance meets the requirements of the following directives:
Low Voltage Device (LVD) – 2006/95/EC.
–
Electro- Magnetic Compatibility (EMC) – 2004/108/EC.
–
The product is marked with CE symbol on the name plate.
Outline
1. Sole plate
2. Temperature Dial
3. Temperature dial pointer
4. Water inlet cover
5. Spraying nozzle
6. Steam control knob
7. Self-cleaning button
8. Burst of Steam button
9. Water Spray button
10. Pilot light indicating the
heater in operation (red)
11. Cord grommet
12. Power cord
How to fill the water
Disconnect the iron from mains sup-
–
ply outlet.
Move the
–
Steam Control Knob (6)
to position.
Release the
–
water inlet cover (4) and
fill water through the water inlet hole.
Fill up to the „
–
MAX” level marked on the side of water tank.
Close the
–
water inlet cover (4).
Note:
For best result, it is advisable to use demineralised water or distilled
water. Do not use chemically descaled water or any other liquids.
