Digital RGB (DVI) Operation
“PICTURE” Operation
When receiving DVI signal, press the “MENU” button firstly on the receiver button board or on the remote control to get into the Picture
menu; press “CH+” or “CH ” to select “PICTURE” item, and then press the “VOL+” or “VOL ” to adjust.
Connect audio connecting cable to “AUDIO 2” terminals of this receiver.
Z
“Color Temp”: “9300k”, “7300k” and “6500k” for option.
“SOUND” Operation
When receiving DVI signal, press the “MENU” secondly on the receiver button board or on the remote control to get into the Sound
menu; press “CH+” or “CH ” to select “SOUND” item, and then press the “VOL+” or “VOL ” to adjust.
“Setup” Operation
When receiving DVI signal, press the “MENU” thirdly on the receiver button board or on the remote control to get into the Setup menu;
press “CH+” or “CH ” to select “Setup” item, and then press the “VOL+” or “VOL ” to adjust.
SCART AV Operation
“PICTURE” Operation
When receiving SCART AV signal, press the “MENU” button firstly on the receiver button board or on the remote control to get into the
Picture menu; press “CH+” or “CH ” to select “PICTURE” item, and then press the “VOL+” or “VOL ” to adjust.
“SOUND” Operation
When receiving SCART AV signal, press the “MENU” secondly on the receiver button board or on the remote control to get into the
Sound menu; press “CH+” or “CH ” to select “SOUND” item, and then press the “VOL+” or “VOL ” to adjust.
29
Eng SVEN STL 2600/STL 3200/STL 4000
Setup
Language English Press right/left to select Language
Source DVI Press right/left to select Source
Osd Tone On Press right/left to select Osd Tone
Size Wide Press right/left to select Size
Brightness 50 Press right/left to adjust the brightness
Contrast 50 Press right/left to adjust the contrast
Color Temp 9300 K Press right/left to adjust the color Temp
Sound
Bass 22 Press right/left to adjust Bass
Treble 50 Press right/left to adjust Treble
Balance +5 Press right/left to adjust Balance
Brightness 40 Press right/left to adjust the brightness
Contrast 76 Press right/left to adjust the contrast
Color 66 Press right/left to adjust the color
Sharpness 18 Press right/left to adjust the sharpness
Sound
Bass 50 Press right/left to adjust Bass
Treble 51 Press right/left to adjust Treble
Balance +0 Press right/left to adjust Balance
Mode Speech Press right/left to select Mode
