8. MENU
Z
In the following illustration figures, the “CH+” or “CH-” is simplified as “up” or “down”; the “VOL+” or “VOL-” is simplified as “right” or
“left”.
Ten seconds after finish the adjustment, the menu disappears automatically or press “MENU” or “ESC” button continuously until the
menu disappears.
TV Operation
“PICTURE” Operation
When receiving TV signal, press the “MENU” button firstly on the receiver button board or on the remote control to get into the Picture
menu; press “CH+” or “CH ” to select “PICTURE” item, and then press the “VOL+” or “VOL ” to adjust.
“SOUND” Operation
When receiving TV signal, press the “MENU” secondly on the receiver button board or on the remote control to get into the Sound menu;
press “CH+” or “CH ” to select “SOUND” item, and then press the “VOL+” or “VOL ” to adjust.
Z
“Mode”: “MOVIE”, “Custom”, “Standard”, “Music”, “Speech” for option.
“Sound mode”: If the sound mode have the stereo mode, this item will display. If not, this item will disappear. In case of bilingual
broadcast. It contains “Mono”, “Dual A” and “Dual B”.
“Setup” Operation
When receiving TV signal, press the “MENU” thirdly on the receiver button board or on the remote control to get into the Setup menu;
press “CH ” or “CH+” to select “Setup” item, and then press the “VOL+” or “VOL ” to adjust.
Z
“Language”: “Chinese” and “English” for option.
“Source”: TV, S-Video, AV, SCART AV, SCART RGB, DVD Component and analog RGB, digital RGB for option.
“Size”: “Fill Screen”, “4:3”, “Wide”, “Cinema”, “Subtitle” for option.
24
OPERATION MANUAL
Brightness
50 –
+
Press right/left to adjust the brightness
Contrast
76 –
+
Press right/left to adjust the contrast
Color
66 –
+
Press right/left to adjust the color
Sharpness
36 –
+
Press right/left to adjust the sharpness
Sound
Bass
50
Press right/left to adjust Bass
Treble
51
Press right/left to adjust Treble
Balance
+0
Press right/left to adjust Balance
Sound Mode
Mono
Press right/left to select Sound Mode
Mode
Speech
Press right/left to select Mode
Sound
Bass
50
Press right/left to adjust Bass
Treble
51
Press right/left to adjust Treble
Balance
+0
Press right/left to adjust Balance
Mode
Speech
Press right/left to select Mode
Setup
Language
English
Press right/left to select Language
Source
TV
Press right/left to select Source
Osd Tone
Off
Press right/left to select Osd Tone
Size
Fill Screen
Press right/left to select Size
