6
ALPHA EVO
U s e r m a n u a l
EN
ALPHA 50 EVO
The ALPHA 50 EVO is an active 2-way nearfield professional loudspeaker (2 internal
amplifiers), comprising a 5" (13cm) mid-bass speaker driver with Slatefiber cone, fitted
with a large-section laminar port and an aluminium inverted dome tweeter
(fig. A) .
ALPHA 65 EVO
The ALPHA 65 EVO is an active 2-way nearfield professional loudspeaker (2 internal
amplifiers), comprising a 6.5" (16.5cm) mid-bass speaker driver with Slatefiber cone,
fitted with a large-section laminar port and an aluminium inverted dome tweeter
(fig. A) .
ALPHA 80 EVO
The ALPHA 80 EVO is an active 2-way nearfield professional loudspeaker (2 internal
amplifiers), comprising a 8" (20cm) mid-bass speaker driver with Slatefiber cone, fitted
with a large-section laminar port and an aluminium inverted dome tweeter
(fig. A) .
ALPHA TWIN EVO
The ALPHA TWIN EVO is an active 2-way nearfield
professional loudspeaker (2 internal amplifiers),
comprising a 6.5" (16.5 cm) mid-bass speaker
driver with Slatefiber cone, fitted with a large-
section laminar port and an aluminium inverted
dome tweeter (
fig. B ).
A
B
C
Midrange
Speaker driver chosen to reproduce the midrange
with the switch set to “left speaker”
Speaker driver chosen to reproduce the midrange
with the switch set to “right speaker”
Midrange
