4.2 Operating the hot plates
Hotplate control position
Application
Corresponding Cooking Values
1
2
1 3
Warming
Simmering Cooking-Frying-Boiling
A rapid heating hotplate is denoted by a red spot
in the centre of the hotplate:
Hoiplaie operaiing knobs
The knobs for the hob can be rotated in either
direction to provide fully variable heat control.
When any one of the hotplates is on, the red
indicator light on the control panel will be on.
In order to switch the hotplate OFF turn the
corresponding knob to the 0 (zero) position. Knobs
of the hotplates can be turned both clockwise and
counter-clockwise directions.
Check tha§ all fhe cooker controls have
heen switched oft after use»
Adjust the hotplates to mid position (3) and leave
on for approximately 8 minutes in order to burn
off the protective coating on the hotplates. Do not
place any pans or other cooking utensil on the
hotplates during this process. Fumes will be emitted
during the above operation but this is quite normal.
Right Pan
(Correit size)
Wrong Pan
(Too smaii)
Good Quality Pans
^ Use only good quality pons having a stable bottom as shown below. This
results in the maximum use of energy.
Use pons for the correct diameter
only. If the pan is too small energy is
wasted.
Do not place pans with wet bases
or pan lids particulary wet lids on the
hotplates damage could occur and
safety problem will be experienced.
Hotplate diameter Suggested diameter
(mm)
of the pan (mm)
0 145 mm (Small) ------------ ^150-170
0 180 mm (Large) ------------ ►/ 80-200
m' Drying the hotplates (max 5 min).
^ When cool;
c«" Clean off solid hotplates with a damp cloth and a little domestic cleaning
cream. After cleaning, dry solid hotplates by switching on for a short time. Apply
a thin coat of cooking oil from to time.
When wiping the hotplates with a damp cloth follow the circular grooved
pattern on the hotplate.
8
