The ceramic hobs are thermostatically controlled
with a 6 level commutator.
One of the stage is the "Off" position. The
application field of the six remaining stages are
given in table.
Fast radiant,dual or extended type hot plates
are energy regulating type, They adjust the
burner operation time of the heater
continuously between 1 st to 3rd stages.
4 . 3 O p e r a t i n g t h e C e r a m i c h o b s
Hob hot i n d i c a t o r l i g h t s
Show which hob is operating and/or hot.
Indicator lights will remain on whenever the
hob is hot. Whenever the temperature of the
hob surface falls below 54 degrees °C limit, the
indicator light will go off.
D o n o t t o u c h a n d k e e p
c h i l d r e n a w a y f r o m t h e
h e a t i n g z o n e s and appliance at all times.
C o r r e s p o n d i n g c o o k i n g v a l u e s
Energy
regulator stages
1
1 3
7 stages
commutator
1 2-3 4 - 5 - 5
Application
Position to Simmering Cooking-roasting
hold hot boiling
Dual or extended burners are energy regulating type adjusting the
operation time of the heater continuous between 1 st to 3rd stages.
Dual burner can heat up at 2 different positions. Saving energy and
time can be achieved by lighting the 1 st stage for small pots and
the 1 st and 2nd stages for large pots. By turning the burner knob
clockwise, the inner part of the burner will heat up. You can use
the 1st, 2nd and 3rd stages according to the applications indicated
in the table. Keep turning the " ® ■" knob in a clockwise direction
starting from the 3rd stage until a " c l i c k " sound is heard to use
the interior and exterior parts of the burner at the same time. Both
stages of the burner will operate. After the completion of the
cooking operation, set the knob to " 0" position by turning it in
a counterclockwise direction.
C a u t i o n : T h e 2 ^ ^ ^ s t a g e o f y o u r d u a l o r
e x t e n d e d b u r n e r s w i l l n o t o p e r a t e b y i t s e l f .
1 0
