1 m^mmmf^ (Pfift) > ¡i§a^^«5ie^«ii
«»
mmsm
i fmmAmi)
VIDEO OUT
AUDIO OUT
VIDEO
2
3i}illilfi1t/a®iuAii?L№ffl51jifflffi0^«ii
{mmmmAmtmm«)
3 m
[VCR/CAMERA] ffl >
SS
[VCR] »
• [VCRli§:5^gOlESE o
4 mi>^mtmmffiWi.m ° (-►62)
Aw^m.RFmm(yA-RnE
^m'-am
Watching Playback on a TV Set
By connecting the Movie Camera to a TV, you can watch
playback of the recorijeci scenes on the TV screen.
Before connecting, turn off both the Movie Camera and
the TV for safety’s sake.
1
Use the AV Cable (supplied) to connect the
Movie Camera with the TV.
Movie Camera
TV (AV Input Sockets)
VIDEO OUT ----------- > VIDEO IN
AUDIO OUT ----------- > AUDIO IN
2
Select the channel on the TV which
corresponds to the video/audio input
sockets used for connecting.
(Refer to the operating instructions of your TV).
3
Press the [VCR/CAMERA] Button to select
the VCR Mode.
•The [VCR] Lamp
Q
lights.
4
Start playback on the Movie Camera.
(-> 62)
If your TV is not equipped with AV Input Sockets, the RF
Adaptor (VW-RF7E; optional) is necessary.
Consult your dealer.
64
