14
CONTROL PANEL
DEODORIZING UNIT
A built-in unit which requires no manual operation because
it automatically starts operating when the refrigerator is
powered on.
DEFROSTING
• Defrosting is fully automatic due to a unique energy saving
system. Whereby the defrost cycle start time is proportional to
the running time of your refrigerator compressor, i. e., the less
time the refrigerator compressor operates (during the winter
season or you're away on holidays), the longer the time
between each defrost cycle.
• The defrost water collects in the evaporating pan, where it is
evaporated by the heat of the compressor, etc.
• The evaporating pan does not require cleaning or
maintenance.
ḥᴾ
МЕНЮ ЭКСПРЕСС
ЛЁД
LCD display
button
Finalizes
the setting.
МЕНЮ button
(CHOOSE)
Press to select the Feature mark.
Plasmacluster
Express Ice Making
Express Freezing
Timer
NOTE:
• When no operation is made for 30 seconds,
the display will automatically return to the
initial content.
The backlight will become dark when there is
no operation for 3 minutes.
The backlight will turn off when there is no
operation for 6 minutes.
• Do not hit or apply sharp object on to the
LCD panel.
Refrigerator temperature setting
Freezer temperature setting
Each feature mark
Use to turn the select.
(Feature ON/OFF, or timer
setting, or temperature setting)
• Marks of features in operation are displayed.
• Features that start automatically
when inserting the power plug.
• When the refrigerator stops with
power failure and the like, display at the time of re-power
distribution shows similarly as before having a power failure.
However, when it has a power failure during operation of
Express Ice Making, Express Freezing, and Timer, operation is
stopped at the time of re-power distribution.
ЗКСПРЕСС ЛЁД button
(EXPRESS ICE)
Press to start Express Ice
Making.
Refrigerator temp. control
Freezer temp. control
Door alarm
Child lock
Vacation mode
button
