DESCRIPTION
1. Door pocket
2. Refrigerator shelf
3. Shelf
4. Bottle pocket (left)
5. Vegetable crisper
The cover of the Vegetable
crisper opens as the case is
pulled.
6. Quick ice maker
The bottom of the tray contains refrigerant material used
in ice packs to speed up the ice making process. The
tray can also be used to freeze small food items such as
meat and fruits by removing the ice making partition.
7. Freezer case (small)
8. Freezer case (large)
9. Casters
10. Adjustable feet
11. Foot cover
12. Aluminum panel
The panel is cooled from the rear, thus indirectly
cooling the refrigerator compartment. In this way, food
is refrigerated gently, without exposing it to cold air
flow.
13. Light
14. Utility pocket cover
15. Utility pocket
16. Egg holder
17. Bottle rack
18. Fruit case
19. Fresh case
20. Bottle pocket (right)
To store large-size bottles,
move the partition all the
way back.
21. Ice cube maker
• Do not over fill the tray;
otherwise the ice cubes will be
joined together when frozen.
• When the ice cubes are made,
turn the lever clockwise to empty
the ice into the Ice cube box.
22. Ice cube box
To prevent damage to the Ice
cube box, do not make ice in the
Ice cube box or pour oil into it.
23. Magnetic door seal
24. Control panel
23
13 12 13
23
14
1
16
15 ( * )
17
18
20
19
24
21 ( * )
22
7
8
23
9
10
1
2
1
3
4
5
6 (
* )
7
8
23
9
10
11
15 ( * )
14
15 (
* )
1
20
16
SJ-F95PS, SJ-F95PE
SJ-F90PS
SJ-F90PE
Partition
Lever
Ice cube box
SJ-F90PS
6. Quick ice maker
1 1 2 2
1 2 1 2
1 0 1 0
15. Utility pocket
21. Ice cube maker
SJ-F90PE SJ-F95PS SJ-F95PE
*
