Head unit
5 9
1 23 4
6 8 7 b a
1 SRC/OFF
2 LEVER
3 MULTI-CONTROL (M.C.)
4 (list)
5 APP
6 BAND/ (iPod control)
7 (back)/ DIMMER (dimmer)
8 MIX (MIXTRAX)
9 1/ to 6/
a DISP
b Detach button
Remote control
c
j
h
1
6 d
g
f i
e
c
VOLUME
Press to increase or decrease volume.
d
MUTE
Press to mute. Press again to unmute.
e
a/b/c/d
Press to perform manual seek tuning, fast
forward, reverse and track search controls.
Also used for controlling functions.
f
AUDIO
Press to select an audio function.
g
DISP/SCRL
Press to select different displays.
Press and hold to turn dimmer on or off.
h
f
Press to pause or resume playback.
i
FUNCTION
Press to select functions.
j
LIST/ENTER
Press to display the list depending on the
source.
While in the operating menu, press to con-
trol functions.
Display indication
1
7 b 9
6 8 a
5 4
2
3
1
Main information section
! Tuner: band and frequency
! RDS: program service name, PTY infor-
mation and other literal information
! USB storage device and iPod: elapsed
playback time and text information
2 Appears when a lower tier of folder or menu
exists.
3 (list)
4 Sub information section
5 LOC (local seek tuning)
6 TP (traffic program identification)
7 TA (traffic announcements)
8 (sound retriever)
9 (random/shuffle)
a (repeat)
b
(iPod control)
This unit ’s iPod function is operated from
your iPod.
Set up menu
1 After installation of this unit, turn the
ignition switch to ON.
SET UP appears.
2 Turn M.C. to switch to YES.
# If you do not use the unit for 30 seconds, the set
up menu will not be displayed.
# If you prefer not to set up at this time, turn M.C.
to switch to
NO.
3 Press M.C. to select.
4 Follow these steps to set the menu.
To proceed to the next menu option, you need to
confirm your selection.
LANGUAGE (multi-language)
This unit can display the text information from a
compressed audio file even for information em-
bedded in English, Russian or Turkish.
! If the embedded language and the selected
language setting are not the same, text infor-
mation may not display properly.
! Some characters may not be displayed prop-
erly.
1 Turn M.C. to select the desired setting.
РУС (Russian)—TUR (Turkish)—ENG (Eng-
lish)
2 Press M.C. to confirm the selection.
CLOCK SET (setting the clock)
1 Turn M.C. to adjust hour.
2 Press M.C. to select minute.
3 Turn M.C. to adjust minute.
4 Press M.C. to confirm the selection.
FM STEP (FM tuning step)
Use FM STEP to set FM tuning step options (seek
step settings).
1 Turn M.C. to select the FM tuning step.
100 (100 kHz) —50 (50 kHz)
2 Press M.C. to confirm the selection.
QUIT appears.
! The manual tuning step is fixed at 50 kHz.
