English - 3

Auto Wall-Mount Adjustment (Sold separately) (Depending on the model)

Once the auto wall mount is installed, your TV’s position can be easily adjusted.

Entering the menu

1. Press the ▲, ▼, ◄ or ► button on your remote control.

The Wall Mount Adjustment screen is displayed.

If the Auto Wall-Mount screen is not displayed when clicking on a direction

button while watching your TV, use the menu to display that screen.

Press the

MENU button to display the menu. Press the ▲ or ▼ button to

select

Setup, then press the ENTERE button.

Press the ▲ or ▼ button to select

Wall-Mount Adjustment, then press

the

ENTERE button.

Remembering the Position

. Adjust to the desired position using the ▲,▼,◄,► buttons.

If you press an arrow button when no OSD is displayed on the TV screen,

the Adjustment screen appears.

Press the

INFO button to reset. Press the ◄ or ► button to select Yes,

then press the

ENTERE button. The position is initialized to the default

setting.

3. Press the blue button. Press the ▲ and ▼ buttons to select a save mode from

either Position 1, Position 2 or Position 3 in order to save the current position.

To not save the current position, press the

RETURN button.

When selecting a save mode, you cannot use the Colour buttons.

4. Press the ENTERE button to save.

When Position1 is selected, the message

Current position saved as Position1 is displayed.

5. Press the ENTERE button.

The saved Position appears on the left side of the OSD.

Moving to the remembered position

1. Complete Step 1 of Entering the menu.
. Pressing a Colour (Red, Green, Yellow) button moves the auto wall mount to the

saved position.

You can move the wall mount to one of the 3 pre-set positions by pressing

the Red (Position 1), Green (Position 2) or Yellow (Position 3) buttons.

If you adjust the Position after moving to a pre-set position, the position

display will disappear.

For installation, refer to the Installation Manual provided with the wall mount.

For product installation and the installation and moving of the wall mount, make sure to consult a specialized installation

company.

This installation manual is to be used when attaching the wall mount to a wall. When attaching to other building materials,

please contact your nearest dealer.

The auto wall mount will not work when

Anynet+ or WISELINK Pro is operating.

N
N

-

-

N

N

N

O

N

N

N

N

N
N

N

N

Setup

Digital Text

: Enable

Light Effect

: Watching TV

Wall-Mount Adjustment

Melody

: Off

Entertainment

: Off

Energy Saving

: Off

PIP

Software Upgrade
Common Interface

Wall-Mount Adjustment

Position

1



3

Adjust Save Centre

Save

Select a mode to save.

Move

Enter

Return

Position1

Position

Position3

Serial Cable(1P to 1P)(Not supplied)

Rear Panel

Auto Wall-Mount
