English - 36

using the remote Control Buttons in the Product guide Menu

Button

operations

Yellow Button

Shows the contents of the

Product guide sequentially. (Auto Play)

◄/►

Move the cursor and select an item.

ENTErE

Select the currently selected item.

rETurN

Return to the previous menu.

EXIT

Stop the current function and return to the

Product guide main menu.

Self Diagnosis

Picture Test

If you think you have a picture problem, perform the picture test. Check the colour pattern on

the screen to see if the problem still exists.

Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes.

There may be a problem with the TV. Therefore, contact Samsung’s call centre for

assistance.
No: If the test pattern is properly displayed, select No. There may be a problem with your

external equipment. Please check your connections. If the problem still persists, refer to the external device’s user manual.

Sound Test

If you think you have a sound problem, please perform the sound test. You can check the sound by playing a built-in melody sound

through the TV.

If you hear no sound from the TV’s speakers, before performing the sound test, make sure

Speaker Select is set to TV

speaker in the Sound menu.
The melody will be heard during the test even if

Speaker Select is set to External Speaker or the sound is muted by pressing

the

MuTE button.

Yes: If during the sound test you can hear sound only from one speaker or not at all, select Yes. There may be a problem with

the TV. Therefore, contact Samsung’s call centre for assistance.
No: If you can hear sound from the speakers, select No. There may be a problem with your external equipment. Please check

your connections. If the problem still persists, refer to the external device’s user manual.

Signal Information (digital channels only)

Unlike analogue channels, which can vary in reception quality from ‘snowy’ to clear, digital (HDTV) channels have either perfect

reception quality or you will not receive them at all. So, unlike analogue channels, you cannot fine tune a digital channel. You can,

however, adjust your antenna to improve the reception of available digital channels.

If the signal strength meter indicates that the signal is weak, physically adjust your antenna to increase the signal strength.

Continue to adjust the antenna until you find the best position with the strongest signal.

Software upgrade

Samsung may offer upgrades for the TV’s firmware in the future. These upgrades can be

performed via the TV when it is connected to the Internet, or by downloading the new firmware

from samsung.com to a USB memory device.

Current Version is the software already installed in the TV.
Alternative Software (Backup) shows the previous version that will be replaced.
Software is represented as ‘Year/Month/Day_Version’. The more recent the date, the newer

the software version. Installing the latest version is recommended.

By uSB

Insert a USB drive containing the firmware upgrade downloaded from samsung.com into the

TV. Please be careful to not disconnect the power or remove the USB drive while upgrades

are being applied. The TV will turn off and turn on automatically after completing the firmware

upgrade. Please check the firmware version after the upgrades are complete (the new version

will have a higher number than the older version).
When software is upgraded, video and audio settings you have made will return to their default

(factory) settings. We recommend you write down your settings so that you can easily reset

them after the upgrade.

N

N

N

N
N
N

TV Rear Panel

or

USB Drive

Self Diagnosis

U Move E Enter R Return

Picture Test

Sound Test

Signal Information

Current Version

2009/01/18_000001

By USB

By Channel
Standby Mode Upgrade

: 45 Min

Alternative Software

2009/01/15_00000

U Move E Enter R Return

Software Upgrade

BN68-01985R-00.indb 36

2009-04-11 �� 4:40:45
