21
Care and maintenance
How to dismantle parts
Freezer
compartment
lamp
Freezer
compartment
shelf
Vegetable
compartment
cover
To remove the vegetable compartment cover,
pull out the vegetable compartment a bit to
the front , lift the front part of the vegetable
compartment cover as shown by , and take
it out. 1
2
• Be sure to remove parts from the refrigerator door when removing the vegetable
compartment and snack corner.
NOTE
Refreshment
center
• Be sure to remove parts from the refrigerator door when removing the vegetable
compartment and snack corner.
NOTE
Separate the lamp by pulling it out while slightly
pressing and rotating the lamp cover.
Turn the bulb counterclockwise. Use a 40-watt bulb
(max.) which can be purchased at a service
center.
To remove a shelf, push the shelf to the left ,
lift the left part of the shelf a bit , lift the right
part up , and take it out.
• Dismantling is done in the reverse sequence of assembly.
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
NOTE
( ) ③
(②) to upward.
Separate the door rack(
①
) to upward.
Separate cover of the refreshment
center
The door rack
can be removed by
pulling it upwards.
