After leveling the
door height
Next
The refrigerator doors will close smoothly by heightening the front side by adjusting
the height adjusting screw. If the doors do not close correctly, performance may be
1. Wipe off all dust accumulated during shipping and clean your appliance thoroughly.
2. Install accessories such as the ice cube box, cover evaporating tray, etc., in their
proper places. They are packed together to prevent possible damage during shipping.
3. Connect the power supply cord (or plug) to the outlet. Don't double up with other
appliances on the same outlet.
When the freezer door is lower than the refrigerator
door
Insert the transparent sheet supplied with the product when the freezer
door is lower than the refrigerator door.
Door replacement
Mount them in the reverse sequence of removal after they pass through
the access door.
Installation
Separate the door with the lower height,use the (+) type screwdriver to unscrew
the screw at the bottom hinge as shown at Figure ,insert the transparent sheet
between the bottom hinge and the bottom bracket, and then fix it with the screw
as shown at Figure . ②
Insert more transparent sheets enough to align the height.
(4 shttes are supplied in total.)
3. After leveling the height of the door,rotate the tightening nut in counterclockwise
direction to tighten it all the way.
When the refrigerator door is lower than the freezer
door
Make adjustments when the refrigerator door is lower than the freezer door
while using the refrigerator.
1. Use the wide side of the adjustment tool ③ to rotate the tightening nut ① in clockwise
direction to loosen it.
2. Use the narrow side of the adjustment tool ③ to rotate the adjustment hinge pin ② in
either clockwise or counterclockwise direction to level the height of the refrigerator
to that of the freezer.
Tightening nut
Raise
C AUTION
Do not adjust the height excessively. You can lose the hinge pin.
①
13
Adjustment
hinge pin
Adjustment
tool
(Height adjustable range: Maximum of 5mm)
Lower
③
②
①
Adiustable supports
can be adjusted when the
refrigerator is not stable.
Adiustable supports
can be adjusted when the
refrigerator is not stable.
