Router ENG
SYMBOLS OPERATING
INSTRUCTIONS
1. INSERT THE ROUTER BIT
Router Bit Selection
Depending on processing and application,
router bits are available in many different
designs and qualities:
Router bits made of high-speed steel
(HSS) is suitable for the machining of soft
materials, e. g. softwood and plastic.
Carbide tipped router bits (HM) is particularly
suitable for hard and abrasive materials, e. g.
hard wood and aluminum.
Use only routing tools with an
allowable speed matching at least
the highest no load speed of the machine.
The shank diameter of the router bit must
correspond with the rated diameter of the
collet.
Inserting Router Bits (See A)
Before any work on the machine
itself, disconnect the mains plug. It is
recommended to wear protective gloves
when inserting or replacing router bits.
Press spindle lock button (14) and keep
depressed. If required, turn the spindle by hand
until the lock engages.
Press the spindle lock button only when at a
standstill.
Insert router bit. The shank of the router bit must
be inserted at least 20 mm (shank length).
Tighten the tightening nut (13) with the spanner
(19) (size 22 mm). Release the spindle lock
button.
Do not tighten the tightening nut
of the collet without a router bit
inserted.
2. MOUNTING THE EXTRACTION ADAPTER
(See B)
To connect the vacuum cleaner via a suction
hose, you must fasten dust adapter (20) to base
plate (10) with both knurled screws (25).
When mounting the extraction
adapter, ensure correct mounting
position!
• For dust extraction, the vacuum hose can be
connected directly to the extraction adapter.
• Clean the dust adapter (20) regularly to
ensure optimum dust extraction at all
times.
• The vacuum cleaner must be suitable for the
material to be worked.
Read the manual
Warning
Wear eye protection
Double insulation
Wear ear protection
Wear dust mask
11 10
