38

Replacing the hard disk

5

Remove the hard disk.

Pull the handle upwards, and then pull out the hard disk from the system.

Notices

The hard disk is a sensitive piece of equipment and should be handled with

care at all times. To help prevent software or data loss or corruption, or

damage to the hard disk, carefully follow the precautions listed below:
 Do not throw or drop the system or hard disk, or otherwise expose either

device to strong vibrations or strong physical impact.

 Do not allow liquid or small particles to get into the system or hard disk.
 Do not touch the connectors or insert foreign objects into the connectors.
 Do not place the system or hard disk close to magnetic fields such as those

produced by magnets or loudspeakers. Also, do not place devices that

may be sensitive to magnetic forces (such as a wrist watch or a credit card)

near the hard disk.

 Do not put heavy objects on the hard disk.
 When handling the hard disk, hold it only by the edges or metal frame.
 The hard disk is sensitive to static electricity. Ensure that proper handling

methods are used when installing the hard disk.

 Store in a cool, dry location.

Replacing the hard disk

Caution

For safety reasons, be sure to turn off and unplug the system before attempting

to replace the hard disk.

When replacing the hard disk, follow the procedure below to remove
the metal frame.

1

Using a crosshead screwdriver, remove the screws (4 places).

2

Hold the hard disk by the edges, and then turn it over.

Grasp firmly by the opening on

either side to prevent slipping.
