TV front panel
TV rear panel
x
TV top control, front and rear
panels
TV top control panel
Button/Terminal
Function
Page
1
!
Turn off or turn on the TV.
4
2
Remote control sensor.
-
3
Wake Up indicator.
11
3
1
Standby indicator.
4
4
i
Headphone jack.
-
5
t2
Video input terminal 2.
8
6
PROG +/–
Select program number.
-
7
2
+/–
Adjust volume.
-
8
t
Select TV or video input.
8
WEGA GATE menu operations
6
,
7
V,v,B,b
Select and adjust items.
12
8
Confirm selected items.
12
9
WEGA GATE
Display or cancel WEGA GATE menu.
12
0
FM
Listen to FM radio.
21
qa
8
Antenna input terminal.
8
qs
T
Monitor output terminal.
9
qd
Component video input terminal.
9
qf
t1
Video input terminal 1.
8
