VACUUM CLEANING
Before you put the vacuum cleaner into operation, you have to execute the following actions:
−
make sure there are bag (1), inlet filter (2) and outlet filter (3) in the vacuum cleaner chamber,
−
put the crooked end of the hose into the vacuum cleaner hole and connect the second end of the
hose (handle) to the telescopic suction tube,
− put the length of the telescopic suction tube into the
operating position as required (depending on the height of
the user) by pressing the button “A” and shifting the tubes in
the direction as shown by the arrows,
− install an appropriate tool e.g. the suction-brush onto the
other end of the suction tubes.
− draw the cord (5) out of the vacuum cleaner body and put
the plug into a network socket.
While drawing the cord out, pay attention to the yellow
band on the cord which denotes the end of the cord.
− Put the vacuum cleaner into
operation by pressing the button (6) ― on the vacuum cleaner and
choose the suitable suction power using the buttons or .
110B
SUCTION POWER REGULATION
The vacuum cleaner is equipped with an electronic suction power regulator which makes possible
a gradual suction power regulation. The suction power regulation can be carried out by using two
micro-switches (
, ): consecutive power stages are being communicated by respective LEDS
burning. Pressing a button according to its markings or results into the suction power getting
increased or decreased.
Putting the vacuum cleaner into operation by using
the power switch does set the operation of the
vacuum cleaner onto the third stage of the suction
power regulation: 3 LEDS on the 5 stage LEDS
bar are burning.
We do recommend the following settings:
1-st stage – to vacuum curtains,
2-nd stage – to vacuum upholstery,
3-rd stage – means cost-effective power,
4-th stage – to vacuum carpets,
5-th stage – to vacuum hard floors and crevices.
Electrobrush
socket
Bag ful
indicator
Switch - off
- button
Suction power
regulation button
Suction power
regulation button
Winder
button
Outlet filter
exchange indicator
