Dustbag replacing, Air-inlet filter replacing – Инструкция по эксплуатации ZELMER 1100
Страница 62
62
DUSTBAG REPLACING
Zelmer vacuum cleaners are equipped with SAFBAG dust bags (amount according to the table above).
Dust bag replacing is necessary when you notice that:
1. When full dust bag indicator is covered with red colour.
2. Safety valve opens.
3. The suction is significantly lower.
4. Dust bag is full.
When the safety valve opens, but you realize that the dust bag is not yet full, we recommend you to
replace the bag, because in unfavourable conditions the fine dust could block the pores on the dust bag
surface, which significantly decreases the sucking power of the vacuum cleaner. When picking up wool
remains, the dust bag can be full, although the full dust bag indicator does not indicate it. In such case
it is also necessary to replace the bag with a new one.
ATTENTION! Do not vacuum without the dust bag.
Remove the hose from the air-inlet.
–
Release the hook of front lid
–
(10), open it.
Holding the bag bar
–
(11) lean it slightly inside (A),
and then remove the whole bag upwards
(B).
Close the SAFBAG dust bag lid, to cover the inlet of
–
the full bag. Dispose it.
Insert the bar of new bag between the runners and
–
move it altogether with a shutter up to the bottom of
the dust-cup, laid the dust bag out. The direction of
dust bag assembling is indicated with an arrow on
the bag.
Close the lid pressing it until you can hear a characteristic clicking sound – be careful not to jam the
–
bag.
ZELMER Company recommends usage of new generation bags:
S A F B A G – SPACE ACTION FILTRATION BAG
Their technical and economic parameters exceed 3 ― 4 times the parameters of traditional
paper bags, which can still be applied.
This dust bag has been made of a special porous material consisting of many
layers. In comparison with traditional paper bag it is characterized with much
better economic and technical parameters.
Due to big plasticity, it fits tightly the dust-cup of the vacuum cleaner, what
–
allows accumulating much more dirtiness (depending on the size of the
dust-cup).
The period from the assembling up to the replacing the bag is approximately
–
3 times longer, which makes the vacuum cleaner operation cheaper.
It has significantly better filtration parameters, which means:
–
more efficient keeping dust,
–
easier air-flow, which enhances engine power and livelong,
–
the same big suction power in spite of filling up the dust bag,
–
much better health protection, as the outlet air is much better cleaned.
–
Hygienic handling – disposable dust bag with a shutter.
–
AIR-INLET FILTER REPLACING
Open the vacuum cleaner such way as in case
–
of dust bag replacing.
Take the air-inlet filter out of the casing
–
(12),
insert a new one, such a way that the inner
filter edge was placed inside the limiting rib
(A)
and close the vacuum cleaner.
10
A
11
B
12
A
