60
insert one end of the flexible hose – (4) into the air intake duct, fit another end of the hose (handle)
with sucking tube,
adjust the length of the telescopic suction pipe in the desired –
working position (depending on user’s height) by moving the knob
in direction indicated by the arrow,
assemble the selected accessory to the other end of the telescopic –
pipe,
pressing the cord re-wind button – (5) pull the cord
out (6) of the casing and insert the plug into power
socket,
ATTENTION! Be careful during pulling the cord
out, the yellow mark on the cord show the end
of the cord.
start the vacuum cleaner up pressing –
the (7) – button,
select appropriate suction power –
moving the cursor (8) according to the
symbols on the vacuum cleaner.
VACUUM CLEANING
Before you start up your vacuum cleaner:
check if the bag is assembled inside the dust cup – (1), air-inlet filter (2) and air-outlet filter (3),
2
3
4
SUCTION POWER REGULATION
The vacuum cleaner is equipped with electronic power regulation, which
enables continuous power regulation. The regulation is executed with linear
potentiometer. Moving the cursor according to the symbols on the vacuum
cleaner results in increasing or reducing power.
The vacuum cleaners 1100 type are also equipped with mechanical suction
power regulation on the hose handle. It is enough to open the valve, as it is
shown in the drawing, to reduce the suction power.
FULL DUSTBAG INDICATOR FUNCTION
When full dust bag indicator is covered (red colour), while the nozzle or brush is elevated over the
cleaning surface, it indicates the necessity to remove or replace the bag. The full dust bag indicator can
operate in case of locking bar the hose or fitted accessories. In such case remove the hose end from
the top lid and clean the hose as well as the fitted accessories.
SAFETY VALVE OPERATION
The vacuum cleaner is equipped with safety valve, which is located inside the dust cup (bag). It opens
automatically when the hose or fitted accessories are blocked or the dust bag is excessively full of dust.
You can hear characterstic „fluttering” sound after valve opening.
1
6
8
7
5
Min. Max.
