D e l l ™ L a t i t u d e ™ C 6 1 0 / C 5 1 0 S y s t e m I n f o r m a t i o n G u i d e
19
Back View
NOTICE: To avoid damaging the computer, wait 5 seconds after turning off the computer
before you disconnect an external device.
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air
vents. Doing so can damage the computer or cause a fire.
Replacing a Battery
CAUTION: Using an incompatible battery may increase the risk of fire or
explosion. Replace the battery only with a compatible battery purchased from
Dell. The lithium-ion battery is designed to work with your Dell™ computer. You
can also use the battery in any Latitude™ C-Family computer
except for Latitude
CS or CS
x computers. Do not use a battery from other CS or CSx computers with
your computer.
NOTICE: To avoid data loss, do not replace a battery while the computer is turned on unless the
computer is connected to an electrical outlet or a second battery is installed.
NOTICE: If you choose to replace the battery with the computer in standby mode, you have up
to 4 minutes to complete the battery replacement. After 4 minutes, the computer shuts down and
you will lose any unsaved data.
1 parallel connector
6
USB connector
2 docking connector
7
fan
3 PS/2 connector
8
serial connector
4 video connector
9
air vent
5 AC adapter connector
9
8
2
3
7
6
4
1
5
