IMPORTANT SAFEGUARDS
u
Household use only. Do not use for
industrial purpose.
u
Unplug
from
outlet
when
assembling and disassembling the unit.
u
Close supervision is necessary when
any appliance is used near children.
u
When carrying the unit be sure to
hold the motor housing with both hands.
Do not carry the unit by holding only
the hopper plate or head.
u
Do not fix the cutting blade and
cutting plate when using kebbe
attachment.
u
Never feed food by hand. Always
use food pusher.
u
Do not grind hard food such as
bones, nuts, etc.
u
Do not grind ginger and other
materials with hard fiber.
u
Continuous running of meat grinder
should be not more than 10 minutes
with the following 10 minutes interval
for motor cooling.
u
Reverse function is prohibited while
the appliance is operating (For example
switch “ON” knob to “R” knob or on the
contrary), wait at least one minute until
grinder has come to a complete stop,
otherwise it may cause an abnormal
noise, vibration or a transitory electric
spark in the appliance. It could result
easily damage to appliance and make a
user frightened.
u
After use, there would be a little
food left in the grinder head. This is
normal. There might be a bit of black
metal powder adhering to the food
ground in the end. Please pick them out
and throw away, do not eat them.
u
To avoid jamming, do not force to
operate the unit with excessive
pressure.
u
When the circuit breaker activates,
do not switch on.
u
Never try to replace the parts and
repair the unit by yourself.
FOR THE FIRST TIME
u
Check that voltage indicated on
the rating label corresponds to the
mains voltage in your home.
u
Wash all parts (except body) in
warm soapy water.
u
Before plugging in, ensure the
“ON/0/ R” switch is turned to "O"
position.
INSTRUCTION FOR USE
ASSEMBLING
u
Holding the head, insert it in the
5
inlet (fig.1). Rotate the head in the
same direction as fig.2 until a small
sound can be heard. The head has been
placed in the inlet. Try to rock the head
slightly to ensure it is placed well.
u
Place the feed screw into the head,
long end first, by turning the feed screw
slightly until it is set into the motor
housing (fig.3).
u
Place the cutting blade onto the
feed screw shaft with the blade facing
the front as illustrated (fig.4). If it is not
fitted properly, meat will not be ground.
u
Place the desired cutting plate next
to the cutting blade, fitting protrusions
in the slots (fig.5).
u
Support or press the centre of the
cutting plate with one finger then screw
the fixing ring until tight with another
hand (fig.6). Do not over tighten.
u
Place the hopper plate on the head
and fix into position.
u
Locate the unit on a firm place.
u
The air passage at the bottom and
the side of the motor housing should be
kept free and not blocked.
MINCING MEAT
u
Cut all foods into pieces (Sinewless,
boneless
and
fatless
meat
is
recommended, approximate size: 20
mm x 20 mm x 60 mm) so that they fit
easily into the hopper opening.
u
Plug in and turn the “ON / R” switch
to "ON" position, then turn the “ON/0/
R” switch to "ON" position.
u
Feed foods into the hopper plate.
Use only the food pusher (fig.7).
u
After use switch the unit off and
unplug it from the power supply.
