14
E. Parental Control
The parental control function works in
conjunction with the different censorship
classes assigned to the DVD's. These
classes help to control the types of
DVD's that families may watch. There
are up to 8 censorship classes for
DVD's.
Press the LEFT/RIGHT button to se lect,
then press the ENTER/PLAY button to
confirm and return to menu.
F. Password Change
You are able to setup and change a
password to manage family viewing. Go
to the preference page and select
PASSWORD from the menu, press the
change key and key-in 6 numbers as
your new password.
NOTE: Make a note of the password so
that you do not forget it.
NOTE: If you change this set, you must
input the password. (The default
Password is 1234)
G. Default
This allows you to reset customized
defaults to the original settings for the
unit (except password). Select Default
on the Preference Page and then press
the ENTER/PLAY button to reset.
Trouble Shooting
Before contacting the nearest service
center or dealer for repairs please check
the following guidelines for possible
causes to problems as well as suggested
solutions.
15
SYMPTOMS CORRECTIONS
No Power • Check to make sure
that the power
connection is secured
and properly connected.
No Picture • Make sure that the
connection between
the player and the TV is
secured and
properly connected.
• Make sure that the TV is
in good working
condition.
• Please press "V-MODE"
button continuously until it
displays a normal picture.
• Make sure that the
connection between
the player and other
devices are secured
and properly connected.
No Sound • Make sure that the TV
and the AMP are
properly setup and in
good working condition.
Failed to play • Check that the disc is
properly inserted.
• Clean the disc.
Failed to
respond to
remote
control
• Remove obstacles
between the remote
control and the unit.
• Aim remote control at
the sensor on the
front panel.
• Check batteries and
replace them if
necessary.
Disturbance • Check the disc for dirt
and scratches.
• Clean or replace disc.
• Shut down the unit.
Wait for ten seconds
and restart the unit.
Key Failure • Power surges, black outs
or other electrical
phenomena.
• Shut down the unit.
Wait for ten seconds
and restart the unit.
Systems and Output
VF Signal
System
NTSC/PAL
Frequent
response CD: 20Hz-
20KHz(EIAJ) DVD:
20Hz^4KHz(96KHz)
(Sample result) 20Hz-
22KHz(48KHz)
(Sample result)
Audio S/N ratio >90dB
Video/Picture MPEG1 V2.0; MPEG2
Audio MPEG LAYER2 standard
Audio output
(analog audio) Electric level output:
1.0-2.0V Resistance:
10KS
Audio output
(digital audio) Electric level
output: 0.5Vp-p
Resistance: 75S
Video output Electric level
output: (1.0 +/-
0.2_Vp-p
Resistance: 75S
Unbalanced
negative
S-Video output Electric level output:
Brightness(Y):1.0Vp-p
Resistance: 75S
Chrominance(C):0.286
Vp~p Resistance:
75S
Component
video
(Y.CB.CR) Electric level output:
0.7Vp-p Resistance:
75S
POWER 25W
Voltage 220~230V
Rated current 0.11A
Frequency 50HZ
