22
Monitor operations
Open/close TFT monitor
1. Press the OPEN/CLOSE button on the panel to open the monitor to the last viewing position.
2. Press the OPEN/CLOSE button to load the monitor to the unit.
Monitor tilt angle adjustment
• Press TILT on the panel or on the remote control to change the display angle,
• You also can turn the monitor position turning it left and right manually.
Image setting
1. Press SEL button on the RC or on the panel to select the setting: COLOR, CONTRAST, BRIGHT.
2. Use
◄/► buttons on the panel or / on the RC to adjust the setting.
Parking cable function
If the PRK SW cable is connected to hand brake switch, the video view to the TFT
monitor will be switched between Normal display and Caution display. Parking cable
function is ceases if Parking is OFF.
When Parking is ON the monitor will show the special screen to prevent the driver
watching other content during driving. The passengers at the rear can watch normally.
Monitor movement mechanism
When any path blocking or obstruction for the movement of the
monitor occurs, the following protection executes to prevent any
damage to the loader or the monitor. After the protection executed
normal operating resumed after the following action of the monitor
performed by pressing the OPEN/CLOSE button or repowering the
unit. If it doesn’t help please reset the unit.
