6
Location of controls
CDX-C8000RX/CDX-C8000R
/MDX-C8500R
D I SC +
PR
S
T +
-
D IS C –
PR
ST
- -
LIST
DSPL
AF
OFF
PTY
ENTER
MENU
SOUND
1 2 3 4 5 6
SOURCE -SEEK/AMS
REP SHUF
TA
OPEN
MODE
DSO
Refer to the pages listed for details.
1 Volume control dial
2 MENU button 9, 13, 15, 16, 17, 18, 19,
21, 23, 24, 26, 27, 29, 30, 32, 33, 34, 38
3 DISC/PRST +/– (cursor up/down) button
9, 13, 15, 16, 17, 18, 19, 21, 23, 24, 26,
27, 29, 30, 32, 33, 34, 38
During radio reception:
Preset stations select 19, 25, 26, 27
During CD/MD playback:
Disc change 13
4 Z (eject) button (located on the front
side of the unit behind the front
panel) 10, 11
5 DSPL/PTY (display mode change/
programme type) button 12, 13, 15,
20, 24, 29
6 LIST button
Disc Memo 15
List-up 16, 28
7 SOURCE (Tuner/CD/MD) button
9, 11, 12, 13, 16, 18, 19, 25, 26, 30, 31,
32, 33, 34
8 Display window
9 OPEN button 8, 10, 11, 39
0 DSO button 32
qa SOUND button 30, 31, 32, 33
qs Reset button (located on the front side
of the unit behind the front panel) 8
qd OFF button* 8, 9, 11
qf SEEK/AMS +/– (cursor left/right) button
9, 13, 15, 17, 19, 21, 23, 24, 25, 29, 30,
31, 32, 33, 34, 38
Seek 17, 18, 19, 25, 27
Automatic Music Sensor 13
Manual search 19
qg ENTER button 9, 10, 13, 15, 16, 17, 18,
19, 21, 23, 24, 26, 27, 28, 29, 30, 32, 33,
34
qh MODE button
During radio reception:
BAND select 18, 19, 22, 25
During CD or MD playback:
CD/MD unit select 12, 16
qj Receptor for the card remote
commander
qk Number buttons
During radio reception:
Preset number select 18, 19, 21,
26, 27
During CD/MD playback:
(1) REP 14
(2) SHUF 14
ql AF button 20, 21, 23
w; TA button 22, 23
* Warning when installing in a car
without ACC (accessory) position
on the ignition key switch
Be sure to press (OFF) on the unit for
two seconds to turn off the clock
display after turning off the engine.
When you press (OFF) only
momentarily, the clock display does not
turn off and this causes battery wear.
