Building-in instructions
Dimensions of housing
Height
(1)
1780 mm
Depth
(2)
550 mm
Width
(3)
560 mm
For safety reasons, minimum ventilation must be as
shown in Fig.
Attention: keep ventilation openings clear of
obstruction.
It is necessary that the niche is provided with a
conduct of ventilation having the following
dimensions:
Depth
50 mm
Width
540 mm
Make sure that a distance of 44 mm is maintained in
the lower part between the kitchen furniture and the
border of the appliance.
The lower hinge cover inserted in the accessories
bag, is useful to guarantee the exact position of the
kitchen furniture and the appliance.
Also make sure that the appliance does not clamp
the mains cable
Fasten the appliance with 4 screws provided in the
kit included with the appliance.
(I = short) (P = long)
Apply the sealing strip pushing it between the
refrigerator and the adjacent cabinet.
