l.S:7iEilgSI(№#)
•
" ( - M 8 )
2.«;tfi(HW)
t l " ( - > 1 8 )
[DC IN] iiiL “
[DC OUT]
ii?L °
3
ai-i-xitifiiigsai#
g
aiiffl
miBiigpititgi
jijit
1
oo^24ov,
50/60Hz)
’
№881SS'SHiz[iffl0i-teiffifl№ii]5J^lilSll
IlsiS ■>
The 3 Types of Power Supplies
To try out the Movie Camera at home, we recommend
that you use the AC Adaptor O-
1. AC Adaptor (supplied)
•To use the Movie Camera indoors.
•To charge the Battery. (->
18)
2. Battery (supplied)
•To use the Movie Camera outdoors, and also indoors
when there is no AC mains socket nearby. (->
18)
3. Car Battery Charger (optional)
•To use the Movie Camera in a car.
Using the AC Adaptor as Power Supply
Unit
1
Connect the DC Input Cable to the
[DC IN] Socket on the Movie Camera.
Connect the other end of the cable to the
[DC OUT] Socket on the AC Adaptor.
Connect the AC Mains Cable to the AC
Adaptor and to an AC mains socket.
2
3
The AC Adaptor features automatic universal voltage
adjustment (AC 100-240 V, 50/60 Hz), therefore, there is
no need for any manual voltage adjustment for use in
other countries.
