Thereafter, in order to prevent excess foam, put
1 ⁄
2
cup of vinegar into the collecting bin.
Excess foaming will not occur after you have
thoroughly cleaned the carpet once with
THOMAS cleaning concentrate, because it
contains a special anti-foam substance.
Ensure that there is always liquid in the
fresh water container when the
spraying function is switched on, in
order to avoid possible damage to the
pump.
Carpet cleaning
A Open the snap-on fasteners and lift the motor
block.
K Remove the lid of the cleaning fluid tank and fill
the tank with THOMAS ProTex Cleaning Fluid.
See the bottle label for dosage instructions.
Use only lukewarm (max. 30 °C) water.
Replace the lid and insert the filled cleaning fluid
tank into the appliance.
G Take the suction hose for cleaning fluid out of its
holder on the motor block.
L Place the motor block onto the collecting bin such
that the suction hose (36) is immersed all the way
to the bottom of the cleaning fluid tank and is not
bent..
J Connect flexible hose. Remove the hose by
turning the hose connecting piece to the side and
withdrawing the hose.
M Insert the cut-off valve into its receptacle on the
suction tube. Snap the handle into the suction
tube and fasten the cleaning fluid hose to the
flexible hose by means of the plastic clips.
N Snap the cleaning fluid hose into the quick
coupling on the motor block.
O Fit the carpet spray extraction nozzle onto the
suction tube.
P Place the cleaning fluid hose of the carpet
spraying nozzle onto the cut-off valve and lock it
in place by turning it. Press the cleaning fluid
hose into the hose receptacle on the suction
tubes, or in the case of stainless steel tubes, fasten
it to the tube with the smaller tube clips (39).
Connect the mains cable.
N Switch on the appliance with the On/Off (6)
switch.
Switch on the pump switch (7).
P Press the hook on the cut-off valve (16).
Cleaning fluid spray will begin.
Before refilling the cleaning fluid tank,
always empty the dirty water from the
collecting bin.
Cleaning hard floors
Q Assemble hard floor adapter.
See ”Carpet cleaning” procedure.
We recommend THOMAS ProFloor cleaning
concentrate for cleaning hard floors.
Cleaning upholstery (according to model)
For cleaning your upholstery or car seats, please use
the upholstery spray extraction nozzle (23).
Take care not to apply too much liquid;
depending on the upholstery sublayer, you may
experience significant drying times.
R Assemble the upholstery spray extraction nozzle.
Fasten the cleaning fluid hose by turning it. Fit the
nozzle onto the handle.
Cleaning and care of the spray extraction
system
K To care for the pump and valves
properly, fill the cleaning fluid tank
with clear water and insert it.
Connect the mains cable. Switch on the
On/Off switch (6) as well as the pump
switch (7).
P Operate the spraying system, e.g. over
a sink (disengage the hook on the cut-
off valve (16)).
N Before removing the cleaning fluid hose, engage
the hook on the cut-off valve (16, figure P) in
order to release the remaining pressure in the
system, and then press the key on the quick
coupling (5).
Remove mains cable!
Afterwards, clean and dry the appliance and the
accessories you have used.
Never immerse the motor block in water!
Clean the motor block casing with a damp cloth and
wipe dry.
