accessories or to the cable (special cable required);
have repairs done only by an authorised customer
service station, because modifications to the
appliance can pose a risk to your health. Ensure
that only original spare parts and accessories are
used.
• Do not expose the appliance to the elements,
humidity or heating sources.
• Never aim the cleaning jet at people or animals, at
electrical sockets or electrical appliances.
• After wet vacuuming, empty the collecting bin
immediately.
• Chemicals such as the cleaning fluid concentrates
should not be handled by children.
• The functionality and complete effectiveness of the
appliance can only be warranted if you use original
THOMAS cleaning fluids.
• Persons with sensitive skins should avoid direct
contact with the cleaning fluid.
• If cleaning fluid comes into contact with mucous
membranes (eyes, mouth, etc.), immediately flush
with water.
We care about the environment
Do not simply throw out packing materials and old
appliances!
Packing materials:
Take the packing carton to paper recycling collection
points.
Take the polyethylene (PE) plastic bag to collection
points to be reused.
What to do with the appliance after the end
of its useful life:
Dispose of the appliance according to local regulations
and pull out and cut off the mains cable beforehand.
Assembly of castor wheels
A Undo the snap-on fasteners and lift the motor
block.
B Push the castor wheels and the pegs into the base
of the collecting bin until they snap into place.
Dry vacuuming
THOMAS BRAVO 20
After wet vacuuming, the appliance must be
absolutely dry; dry off the flexible hose or tubes
if necessary beforehand.
Never dry vacuum without filters or
with damaged filters.
K Remove the cleaning fluid tank.
C Assemble the foam rubber filter, tissue filter and
clamping ring and fasten them with the turning
clips.
D Press the filter sack on the suction connection
firmly and lay it against the wall of the collecting
bin.
G Clip the hose for the cleaning fluid to the
underside of the motor block.
H Place the motor block on top and secure it by
means of snap-on fasteners.
J Connecting the flexible hose. Remove the hose by
turning the hose connecting piece and
withdrawing the hose.
Assemble the accessories you require.
Connect the mains cable.
N Turn the appliance on with the On/Off switch.
The pump switch (7) must not light up.
Suction control (11, figure P) allows you to vary
the suction power.
– Sliding air trap closed = full suction power
– Sliding air trap open = reduced suction power
THOMAS BRAVO 20S Aquafilter
Never use your AQUAFILTER appliance in dry
vacuum mode without the Aquafilter, the fine
particle textile filter and an appropriate water
level.
Do not vacuum up large quantities of particle
dust, e.g. flour, cocoa powder, cement, etc.
12
