SoundMax SM-2402 - Инструкция (Страница 5)

5
Stereo headphone connecting
• For private listening, insert 3.5 mm headphone into the stereo headphone jack.
• Adjust volume control to the appropriate level as desired.
• When the stereo headphone jack is plugged, speakers will disconnect automatically.
Radio operations
• Press the Power button to turn the unit on.
• Slide the function switch to radio position.
• Select the desired band with Band Selector.
• Adjust the Tuning Control to tune in a radio station.
FM and FM stereo reception
• In particular when stereo signal is weak and much noise are received, it is preferable to receive the
program in mono. Slide the band selector to switch between FM stereo and mono modes.
• If the program is received in FM stereo, "FM ST" indicator will light up.
Antenna
• For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band
selected.
• The AM signal is picked up through the built-in ferrite antenna. The set should be placed to a position for
the best reception.
Cassette tape playback
• Slide the FUNCTION switch to TAPE position.
• Press the STOP/EJECT button to open the cassette compartment.
• Insert a cassette with the tape-side up into the proper Guide-rails on the inside of the cassette door.
• Gently push the cassette door forward (inwards) to close it.
• Press the PLAY button to start the playing.
• Adjust the level of sound with VOLUME knob.
Cassette controls
• Press the PAUSE button to pause the playing.
