4. FRONT AND REAR PANEL DESCRIPTION
(1) Infrared receive window
(2) Display window
(3) 5.1 Virtual Surround indicator light
(4) Standby indicator light
(5) Stereo indicator light
(6 11) 5.1 Channel inputs
(12) Tuner input terminal
(13) TV input terminal
(14) DVD input terminal
(15) Left Front channel output jack
(16) Center channel output jack
(17) Right Front channel output jack
(18) Left Surround channel output jack
(19) Right Surround channel output jack
(20) Power switch
(21) AC power socket
5. THE REMOTE CONTROL INSTRUCTION
(1) 5.1 CH input selector
(2) Standby button
(3) TV input selector
(4) Tuner input selector
(5) Center & surround &subwoofer channel volume adjusting selector
(6) 5.1 Virtual Surround
(7) Master volume control buttons
(8) Treble control buttons
(9) Bass control buttons
(10) Center & surround & subwoofer selector
(11) DVD input selector
(12) Muting button
5.1 REMOTE CONTROL PREPARATION
Remove back cover of Remote Control and place two “AAA” size batteries.
Operation range is about 7 meters with ± 30° spanning angle.
