20
ENG
ENGLISH
ASSEMBLING AND PREPARING
A
B
cAUTION
y Disconnect the power first, and then move
or install the TV. Otherwise electric shock
may occur.
y If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
y Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
y Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
NOTE
y Use the screws that are listed on the VESA
standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The wall mount bracket is not provided. You
can obtain additional accessories from your
local dealer.
y The length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
y For more information, refer to the manual
supplied with the wall mount.
y When attaching a third-party wall mounting
bracket to the TV, insert the wall mount
inner spacers into the TV wall mount
holes to move your TV in vertical angle.
Please make sure not to use the spacers
for LG wall mounting bracket. (Only
32/37/42/47/55LM61**, 32/42/47LM58**,
32/37/42/47LS56**)
Wall Mount Inner Spacer
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described in
the following table.
Separate purchase (Wall Mounting Bracket)
Model 32LM34** 32/37LM61**
32LM58**
42LM34**
32/37LS56**
47CM96**
VESA (A x B) 200 x 100 200 x 200
Standard
screw
M4 M6
Number of
screws
4 4
Wall mount
bracket
LSW100B LSW200BX
LSW220BX
Model 42/47/55LM61**
42/47LM58**
42/47LS56**
VESA (A x B) 400 x 400
Standard
screw
M6
Number of
screws
4
Wall mount
bracket
LSW400BX
LSW420BX
