20
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
Attach a wall mount bracket at the rear of the TV
carefully and install the wall mount bracket on a
solid wall perpendicular to the floor. When you
attach the TV to other building materials, please
contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
Make sure to use screws and wall mount bracket
that meet the VESA standard. Standard
dimensions for the wall mount kits are described in
the following table.
Wall mount bracket
Model 47/55LM96**
42/47/55LM86** 84LM96**
72LM95**
VESA (A x B) 400 x 400 600 x 400
Standard
screw
M6 M8
Number of
screws
4 4
Wall mount
bracket
LSW400BX
LSW420BX
LSW600B
A
B
10 cm
10 cm
10 cm
10 cm
Securing the TV to a wall
1
Insert and tighten the eye-bolts, or TV brackets
and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to the
wall.
Match the location of the wall bracket and the
eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly
with a sturdy rope.
Make sure to keep the rope horizontal with the
flat surface.
This feature is not available for all models.
y Make sure that children do not climb on or
hang on the TV.
CAUTION
y Use a platform or cabinet that is strong and
large enough to support the TV securely.
y Brackets, bolts and ropes are not provided.
You can obtain additional accessories from
your local dealer.
NOTE
