Do these steps to clean the filters:
1. Open the door.
2. Remove the basket.
3. Remove the filters in the bottom of the
appliance.
4. Clean the filters below running water.
5. Put the filters back.
6. Turn the microfilter clockwise to lock it.
7. Close the door.
Cleaning the spray arm
Regularly examine the spray arm. Remove
remaining food from the holes in the spray
arm.
Do these steps to remove the spray arm:
1. Turn the nut anticlockwise.
2. Remove the spray arm.
3. Fully clean the holes.
External cleaning
Clean the external surfaces of the appliance
and control panel with a damp soft cloth.
Only use neutral detergents. Do not use
abrasive products, scouring pads or solvents
(acetone, trichloroethylene etc...).
Frost precautions
Caution! Do not install the appliance
where the temperature is below 0 °C.
The manufacturer is not responsible for
damage because of frost.
If not possible, empty the appliance and
close the door. Disconnect the water inlet
hose and remove water from the water inlet
hose.
Technical data
Dimensions Width cm 54,5
Height cm 44,7
Depth cm 48-49
Electrical connection - Voltage -
Overall power - Fuse Information on the electrical connection is given on the rating plate
on the back of appliance.
Water supply pressure Minimum 0,8 bar (0,08 MPa)
Maximum 10 bar (1,0 MPa)
Capacity Place settings 6
What to do if…
The appliance does not start or stops during
operation.
If there is a fault, first try to find a solution to
the problem yourself. If you cannot find a sol- ution to the problem yourself, contact the
Service Force Centre.
