DISC CARE
Differences in disc composition
DVD
All discs are divided up into smaller, more manageable sections
so that you can find specific content more easily. DVD discs are
divided into one or more titles. Each title may be further divided
into several chapters. Occasionally, a chapter may contain index
points, effectively dividing the chapter up into several parts, too.
MULTI ANGLE
You can view scenes from different camera angles when watch
ing movies or other media with multiple angle playback avail
able.
MULTIPLE LANGUAGES
You can select the expected language on when watching
movies or discs that have multiple languages and/or
audio soundtracks recorded on them.
MULTI LANGUAGE SUBTITLES
You can select the expected subtitle language or turn subtitles
off when watching movies
or discs that have multi language subtitles recorded on them.
SVCD/VCD/CD
SVCD/VCD/CD are divided into a number of tracks. A track may
contain a number of index points occasionally, which effectively
divides the track up into several parts.
MP3 /JPEG
MP3 is a compressed audio file format. Files are recognized by
their file extension ".mp3" or ".MP3". JPEG is a compressed
image file format. Files are recognized by their file extension
".jpg" or ".JPG".
MP EG 4
MPEG 4, an extension of MPEG 2 technology, is a format with
high image quality and low data transmission rate. With the sup
port of MPEG 4 technology, the image quality of video files on a
CD ROM, whose capacity is only 700 MB, can reach or approach
the image quality of DVD. The player identifies this type of file by
judging whether the file extension is ".AVI" or ".avi".
OPERATION GUIDE
INTRODUCTION OF PRODUCT FUNCTIONS
This appliance adopts Taiwan SunPlus latest DVD decoder chip
that integrates functions of decoder and servo. It supports full
functional DVD playback modes including 8 languages,
32 subtitles and 9 angels. The appliance can play DVD, super
VCD, VCD, DVCD, CD and CD R discs. In addition, MP3 and
Picture CD are also playable.
The player has the following features:
• The latest ultra slim DVD.
• Supports MPEG 4/DivX Technology.
• Built in DOLBY DIGITAL with 6 channel audio output.
• 10 bit/27MHz 60Mhz video D/A converter with up to 500
line horizontal resolution.
• 24 bit/192KHz audio D/A converter with high quality DVD
audio output.
• 3D virtual surround sound effect and 6 reverb modes.•
• Coaxial digital audio out jack, standard 6 channel audio out
jack.
• Standard video out (AV), S video out, component video out
(Y, Pb, Pr) and VGA video out.
• 16:9 and 4:3 TV screen aspect ratio support.
• Playback functions including Repeat, Fast Forward/Reverse,
Zoom In/Out, JPEG,etc.
• Parental Lock Level control system.
• High reliability power supply switch and wide power require
ment range (AC 110 240V, 50/60Hz).
• Screensaver program for screen protection.
• Auto STANDBY function for automatic electricity saving.
• Super search function, supporting various search modes.
INTELLIGENT UPGRADE
• Load the upgrade disc, the player will upgrade its software
automatically.
• The player will enter standby status after the upgrading
process is finished.
Caution: Do not turn the power off during upgrading. If acci
dents such as power failure result in upgrading failure,
please refer servicing to the maintenance center.
ENGLISH
3
