DOLBY DIGITAL SETUP
OP MODE
LINE OUT: This mode will output a bigger sound, which suits the
daytime.
RF REMOD: The output will be linear compressed and has a
smaller volume, which suits the quiet night.
DYNAMIC
In Dolby Digital mode, dynamic range compression can reduce
suddenvolume changes by letting you adjust the difference
between soft and loud sounds. With this function, you can enjoy
the surround sound effect while viewing discs in mid night with
out disturbing others.
Ratio of dynamic range compression includes FULL, 6/8, 4/8,
2/4 and OFF.
DUAL MONO
Different setting can be applied to the left and right channel
when audio
output is only two channel.
STEREO: output left channel audio to left channel and right to
right.
MONO L: output left channel audio to both channels.
MONO R: output right channel audio to both channels.
MIX MONO: mixed left and right channel audio and output to
both channels.
Note: only for discs recorded in Dolby MONO format.
PLAYABLE DISC TYPES/SPECIFICATIONS
Above disc type mark can be found on disc labels or disc jack
ets. CD R and CD RW discs recorded in CD Audio or Video CD
format, or with MP3 audio files, are also playable.
Caution!
• CD R/RW discs recorded using a personal computer may
not play if the disc is damaged or dirty, or if there is dirt or
condensation on the player's lens.
• If you record a disc using a personal computer, there are
cases in which it may not play because of the settings of the
application software used to create the disc. (Check with the
software publisher for more detailed information.)
SPECIFICATIONS
Environment:
working temperature :
0 ~ 40°C
working humidity : 10% ~ 80%
Video:
Color system :
PAL/NTSC
DVD horizontal resolution : 500 line
SVCD horizontal resolution : 350 line
VCD horizontal resolution :
250 line
Audio:
Signal to noise :
90 dB
Frequency response : 20 Hz ~ 20 KHz +1 dB
Distortion and noise : 70dB
Dynamic range : > 80dB
Crosstalk : 80dB
Output:
Video output level :
1.0 0.2 Vp p
Audio basic output level : 1.8V
Remote control
effective distance:
not less than 6m;
angle : (horizontal/vertical) ±30°C
Power requirement: AC 110 240V 50Hz/60Hz
Power consumption: 15W
Dimensions: 430mmx260mmx38mm
Weight: approximately 2.5 kg
ACCESSORIES
Remote control 1
Audio / Video cable 3
AAA dry cell batteries 2
User,s manual 1
ENGLISH
