3. Assemble cable jack with the base part as illustrated
in Figure 3.
4. Find a pole which is over 5M long and 22~39mm in
diameter and screw it with the base tube as indicated in
Figure 4.
Note: A bamboo pole is preferred. If a metal one is
used,be sure it is isolated.
5. Put up the pole and make a loop with the
cable cord. The loop which is 15cm in diameter
to prevent water from going down into the base
unit (as figure 5).
6. The assembled outdoor antenna
(as indicated in Figure 6).
12
