Vacuuming:
•
Before use ensure that you have released a sufficient length of cable, then
plug the device into the wall socket. The ideal cable length is identified on
the cable by a yellow marking. When unrolled, the cable should not exceed
t h e m a x i m u m l e n g t h . T h i s i s i d e n t i f i e d b y t h e r e d
marking.
• Turn on the model cyclone vacuum cleaner by gently tipping the foot to
press down on the ON/OFF switch.
Note:
On rare occasions it is possible that a “whistling” soundmay be heard when
the device is switched on. This will cease after a short period and
does not indicate the presence of fault.
Stop:
Never use the device to vacuum clay, cement, drill or plaster. These materials
will block the filter.
Varying the suction capacity:
You can use the suction capacity regulator to select individual suction
requirements. Turn the regulator forth in order to increase the suction
capacity, back to decrease it.
•
MIN: This level is ideal when vacuuming sensitive materials such as
curtains.
• MIN-MAX: The middle level is suitable for upholstered furniture, carpets
and mattresses.
• MAX: This level should only be used for robust flooring such as wood and
tiles.
Secondary air valve:
The secondary air valve, which is located on the device handle, allows you to
control the suction power of the model cyclone vacuum cleaner more finely.
It is recommended that the secondary air valve be opened when cleaning
curtains etc. in order to avoid them being drawn in to the device.
To open: push forwards
To close: push backwards
After vacuuming:
Once you have finished vacuuming turn the device off:
•
Use either the foot or the hand to press the ON/OFF switch on the
cyclone vacuum cleaner.
• Remove the plug from the wall socket. (Never pull on the cable, always
apply light pressure to the plug housing)
• Take the plug in your hand in order to avoid the cable flicking up during the
winding process. Press down on the cable rewind button with the foot until
the cable has rewound completely onto the cable drum, which
is inside of cyclone vacuum cleaner.
• In order to place the device in its parking position, use the hook located
above the floor nozzle to guide it into the cyclone vacuum cleaner nozzle
holder.
The Filter
The cyclone vacuum cleaner functions without a dust bag. The cyclone
technology directs the dusty intake air into the dust receiver tank using air
turbulence. The washable long-life filter (Filter) in the dust receiver tank and
an exhaust air filter combine to ensure that the air is clean before it is
expelled.
Attention: The device must only be used with the filter and exhaust air filter
in place.
Emptying the dust receiver tank:
The dust receiver tank is transparent, which means that you are always able
to see how full it is. You should always empty the dust receiver tank by the
time its contents reach the MAX mark.
Always unplug the appliance before emptying the dust receiver tank!
You can now remove both the tank and the cleaning system from their
anchored position using the carry handle located on the dust receiver tank.
Now simply carry the dust receiver tank to the dustbin.
