Equipments:
1. 3 wheels
2. Washable long-life filter
3. Automatic cable rewind
4. Maximum motor capacity 2200W
5. Exhaust air subject to multi-filter process
6. Electrical regulation of the suction capacity
Technical data:
Main connection: 230V/50Hz
Capacity: 2200W
GS CE EMC EMF
We reserve the rights to make changes to the scope of deliverables,
equipment and the technical data!
Filter cleaning system:
The cleaner 2200W cyclone vacuum cleaner is fitted with a unique filter
cleaning system. This allows you to remove the dust from the receiver tank in
a completely new, clean and comfortable manner.
Explanation of accessories:
You will receive two different nozzles with your 2200W cyclone vacuum
cleaner. These allow the device to be utilized for a variety of applications.
Floor nozzle:
The floor brush is the fitting most commonly used. That perfect for us on
large, even areas. The 360 joint allows the nozzle to gain access to every
corner, with ease and without complication. The toggle switch provides you
with the option of using the floor nozzle with a range of floor coverings:
1. For carpets: Push the toggle switch to select the symbol for carpet. By
pressing the toggle switch you will have lowered the brushes.
2. For polished floor coverings, press the toggle symbol for smooth flooring.
Brush nozzle:
3. The brush nozzle is the best fitting for cleaning sensitive surface such as
picture frames or books.
Crevice nozzle:
The crevice nozzle is well suited to the vacuuming those areas that you are
unable to gain access to tight spaces, material folds corners and niches.
Assembling your 2200W
Cyclone vacuum cleaner:
Attention:
Before attaching or detaching any accessories always ensure that you unplug
the power supply from the wall socket!
1. Attaching or detaching the hose:
To attach: Push the vacuum hose into the air intake opening until it snaps
into place.
To detach: Push the button on the vacuum hose to release the hose.
2. Attaching the telescopic tube and its accessories:
• Set the telescopic tube to the desired length. In order to do this simply
push the slide on the telescopic tube forwards before pulling on the
lower part of the tube until it has reached the length required. Once
you have selected the optimum length, let the slide return to its
original position and ensure that it snaps shut.
• Now attach the floor brush to the telescopic tube as shown in the
diagram. Attach the crevice nozzle and brush nozzle using the same
method.
• Mount the telescopic tube onto the handle
