MAINTENANCE
Note:
After several use of your iron, a little amount of limescale will be built up in the
steam chamber and steam outlet, following up below self-cleaning process, it will
be well removed.
1. Set the adjustable steam control knob to”0” position.
2. Fill reservoir with water to max filling line.
3. Place the iron on the ironing rest, and place a sink
under the ironing rest to prepare for pouring water
and ejecting steam.
4. Set temperature control dial to “ l l l ”position.
5. Plug the unit into the main socket.
6. Allow the iron to heat up for 2 minutes.
7. Disconnect the iron from main socket.
8. Hold the iron horizontally over the sink.
9. Push the self-cleaning button.
10. Boiling water and steam will emit from the outlet in soleplate and wash away
the impurities and scale.
11. Move the iron backwards and forwards while this happens. Go on letting
steam and water escape until the water tank is virtually empty.
12. Insert the iron into main socket again.
13. Set the temperature control dial to “ l
l l ” position, Let the iron heat up again.
The remainder of the water inside the steam chamber will now vaporize.
14. Unplug from power supply and allow soleplate to cool down and wipe it clean
with a soft damp cloth.
Never use scouring pads, abrasive or harsh cleaners as this may scratch the
surface.
P/7 P/8
www.vitesse.ru
VERTICAL STEAM IRONING
ANTI-DRIP SYSTEM
ANTI-CALC SYSTEM
Vertical steam ironing is especially used for removing creases from hanging
clothes and curtains
1. Set the steam control knob to “0” position, fill water into water tank as
described in water filling instruction.
2. Connect the appliance to suitable power socket, and then set temperature
control dial to the max temperature setting. The heating indicator light will light
up, which indicate that the unit being heated up, When the heating indicator
light turn off, the required temperature is reached. It is ready for vertical steam
ironing
3. Hold the iron in vertical position as shown in figure 6,
and then press down the steam button, vertical steam
will go out from the steam outlet of the sole-plate.
4. After use, turn adjustable steam control knob to “0”
position, disconnect the appliance from power socket
5. Before storing, please allow the unit completely cool
down Caution: Never perform steam ironing directly
on person.
This appliance has a safety mechanical protection that can protect water drip from
the sole-plate when the temperature of steam chamber is so low that it cannot
provide steam.
The anti-calc box is designed to purify hard water and reduce the buildup of
limescale which occurs during steam ironing, this will prolong the working life of
your iron. Note : The anti-calc box should be replaced with a new one after two
months, in case of using one time each day, and you can contact with
manufacturer or agency for purchasing a new one.
Fig.6
Fig.7
Fig.8
