IRONING TEMPERATURE SETTING GUIDE
1. Follow up the ironing instructions on the garment label. If there is not any
instruction label, but you know what kind of the fabric is, please refer to the
FABRIC SETTING CHART described in this instruction manual.
2. The fabric setting chart is only valid for plain fabrics and not for materials to
which finishes, glosses etc., have been applied. Textile to which some kind of
finish has been applied (gloss, crinkle, relief etc.) is best ironed at lower
temperature.
3. First sort laundry according to ironing FABRIC SETTING CHART: wool with
wool, cotton with cotton, etc.
4. The iron heats up more quickly than it cools down. Therefore, start ironing
articles that need to be ironed at the lowest temperature, such as those made
of synthetic fibres.
5. If the fabric consists of various kinds of fibres, always select the temperature
required by the most delicate fibres, i.e. the lowest temperature. If, for
example, an article consists of 60% polyester and 40% cotton, according to
the fabric setting chart it should be ironed for polyester and without steam.
6. If you do not know what kind of fabric the article is made of, iron a piece of the
material which is not visible when you wear to find out the appropriate
temperature for your articles.
7. Pure woolen fabrics (100% wool) should be ironed with the iron setting to
steam ironing position. It is advisable to set the temperature control dial to
“Max” position and use a dry pressing cloth.
8. When steam ironing woolen fabrics, shiny patches may occur. You may
prevent this by turning the article inside out and ironing the reverse side.
9. After using of steam ironing for cotton fabrics, do not iron articles required by
lower temperature (such as nylon etc.) immediately. It is advisable to adjust
the temperature dial to the lower setting, waiting for about 2-4 minutes till the
power indicator light turn off, and then you can start ironing.
HOW TO FILL RESERVOIR
Note:
Make sure that the iron is unplugged from main socket or steam control knob is set
at “O” position before filling water into the reservoir.
1. Set the steam control knob to”0”position as shown in figure 2.
2. Open inlet cover and take Anti-calc box upwards out of the filling hole (Fig.3).
3. Using a cup, slowly pour tap water or distilled water into the reservoir as show
in figure 4. Never to fill beyond the Max filling line.
4. Replace the Anti-calc box back into the filling hole as show in figure 5.
5. Hold the iron in horizontal direction, and then move the iron front and back for
about 30 seconds so that limescales in water can be purified by the ion
exchange resin in the Anti-calc box.
When using distilled water, you can mix it with tap water in a proportion of 50%.
Fig.2
Fig.3 Fig.4 Fig.5
Min Off
Synthetic
Silk/Wool
Cotton
Max
Fabric Setting Temperature Setting
Dr
such as Nylon, Acrylic, Polyester y iron for lower ironing temperature,
Dr
temperature, such as Silk Wool y iron for mid ironing
Dr
such as Cotton/Linen y iron for higher temperature,
Steam iron for all fabrics
Ironing Instruction
FABRIC SETTING CHART
