6
OPERATING INSTRUCTIONS
Assembly
1. Place the juice extractor on dry level surface.
Make sure than the switch (13) is in «0»
position.
2. Install the pulp container (6), by matching the
juice spout (8) with the groove on the body (10).
3. Put the grater/filter (5) inside the pulp container (6) so that it
completely fits into the driving shaft (12) until click. Check that
the grater/filter (5) rotates freely. Put the feeder tube of the
large pusher (3) above.
4. Insert the feeder tube of the large pusher (3) into the pulp con-
tainer (6) matching the projections on the feeder tube of the large
pusher (3) with the safety clamps (9).
5. Lift the safety clamps (9) and put them down so that they lock on
the projections of the feeder tube of the large pusher (3).
Note:
The juice extractor has a safety system. If the safety
lock (9) is not securely fastened, the appliance will
not operate.
6. Place any juice cup under the juice spout (8).
7. In order to stop juice dripping after the operation there is a juice
stopper (7): lift the juice spout (8) matching the ledge on it with
the anti-drip hole (7).
Disassembly
1. Make sure that the appliance is switched off and unplugged
from electrical outlet.
2. Take both pushers (1, 2) out of the feeder tube of the large
pusher (3). Lift the safety clamps (9) and move aside and down.
3. Remove the feeder tube of the large pusher (3). Then remove the
grater/filter (5).
4. Unfasten the pulp container (6). Remove the juice spout (8).
10.Body
11.Rubber foot
12.Driving shaft
13.Three-position switch «0/I/II»
BEFORE USE
!
Remove all packing materials from the ap-
pliance.
!
Wipe the appliance body with soft damp cloth,
thoroughly wash all the appliance parts com-
ing into contact with food.
