Palm Sander ENG
9 8
18. Your tool is designed for general purpose
light polishing of wood and metals.
19. Do not sand magnesium material due to the
risk of fire.
WARNING: Some dust particles
created by power sanding, sawing,
grinding, drill and other construction jobs
contain chemicals known to cause cancer,
birth defects or other reproductive harm.
Some examples of these chemicals are:
Lead from lead-based paints.
Crystalline silica from bricks and cement and
other masonry products.
Arsenic and chromium from chemically
treated lumber.
Your risk from these exposures varies,
depending upon how often you do this type
of work. To reduce your exposure to these
chemicals:
Work in a well-ventilated area.
Work with approved safety equipment,
such as those dust masks that are specially
designed to filter microscopic particles.
SYMBOLS
Read the manual
Warning
Wear eye protection
Double insulation
Wear hearing protection
Wear dust mask
OPERATING INSTRUCTIONS
1. ON/OFF SWITCH
To start your sander, depress the protective
cover over the switch at the position marked“I”.
To stop your sander, depress the protective
cover at the position marked “0”.
2. HAND GRIP AREA
You can operate your sander with one hand
(see A).
3.CHANGING THE SANDING PAPER
To remove the sandpaper, lift up the clamp
lever (4) and move away from the lever lock (5)
(see B). The sandpaper clamp (3) is now loose.
Repeat with the other clamp on the opposite
side of your sander.
To fit new sandpaper, insert approximately
5mm of one end of the sandpaper under the
sandpaper clamp (3) until the paper contacts
the housing wall (see B). Lift up the clamp lever
(4) and move it to the lever lock position.
Press the sandpaper around the base-plate
shape as tight as possible and fix the end
under the other sandpaper clamp (3). Check
the sandpaper is square to the base-plate and
remove and refit again if not correct.
Always, ensure the sandpaper is tight over the
base-plate and secured underneath both locked
clamps (3). This will ensure safe and efficient
sanding performance.
4. CHANGING HOOK & LOOP SANDING
PAPER
The sanding paper and baseplate are provided
with a hook and loop attachment system to
allow quick and easy changing of the sanding
and polishing accessories. Remove any dust
or other objects from the hook and loop on
the baseplate and sanding paper. Position the
sanding paper evenly on the baseplate and
firmly press down to attach them together. If
the sanding paperhas dust extraction holes you
must align these with the holes in the baseplate,
otherwise the dust extraction will not function.
To remove the sanding paper lift one corner of
the paper and pull it off from the baseplate (See
B.2).
