Palm sander eng, Technical data noise and vibration data, Accessories – Инструкция по эксплуатации WORX Tools WU645
Страница 6
Palm Sander ENG
Rated voltage
220V-240V~50Hz/60Hz
Rated power
240W
Rated no-load speed
15,000min
-1
Base size
103 x 110mm
Orbital diameter
1.6mm
Double insulation
Machine weight
1.2Kg
TECHNICAL DATA
NOISE AND VIBRATION DATA
A weighted sound pressure
80.1dB (A)
A weighted sound power
93.1dB (A)
Wear ear protection when sound pressure is over
85dB (A)
Typical weighted vibration
8.6m/s
2
ACCESSORIES
Sander paper
1pc
Paper hole punch
1pc
Dust bag
1pc
Use 1/4 sheet sanding paper of the following size
140 x 115mm for no hook & loop(Clamp only)
102 x 115mm for hook & loop
If using sanding paper without dust holes, you must use the paper punch to make
holes.
We recommend that you buy all your accessories from the store where you purchased the tool.
Use good quality accessories marked with a well-known brand name. Choose the grade according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can also help and advise.
07
06
1. ON-OFF SWITCH
2. HAND GRIP AREA
3. SANDPAPER CLAMP
4. CLAMP LEVER
5. CLAMP LEVER LOCK
6. DUST BAG
7. PAPER PUNCH
8. BASE PLATE
9. HOOK AND LOOP SYSTEM
