12 13
Operation Operation
current mode information on the display.
Setting the sound characteristics
Press SEL button to open the following menu:
1 2 3 4
1. Setting list. Touch a setting to select its
adjustment.
2. Adjustment buttons. Touch them to adjust
corresponding setting.
3. Page selection buttons. Touch to select a
menu page.
4. Return button. Touch to return to previous
menu level.
Following settings are available for
adjustment:
Page 1
• Equalizer: Select Flat, Classic, Pop, Rock
or DSP OFF equalizer mode.
• TA volume: Adjust the volume level for TA
radio service.
Page 2
• Bass: Adjust the low-frequency level.
• Treble: Adjust the high-frequency level.
• Balance: Adjust the balance between left
and right channels.
• Fader: Adjust the balance between front
and rear channels.
Page 3
• Beep: Select ALL (beep is heard at any
button pressing), 2ND (beep is heard when a
button is pressed and held) or OFF (no beep).
• Loud: Selecting loudness ON will
emphasize the low frequency output.
• Subwoofer: set the subwoofer on or off.
You can also press / buttons on
the RC to select menu pages; press UP/DOWN
cursor buttons to select a setting, press LEFT/
RIGHT buttons to adjust the setting.
AV in jack
AV jack is intended to receive audio and video
signals by connecting to external device.
Subwoofer
Connect a subwoofer to this unit using the
Subwoofer output of this unit. For subwoofer
operation an external amplifier is required.
Dual zone function
DUAL - dual zone function enabling user to
listen to radio or watch TV in the front zone,
and at the same time play audio or video from
disc, USB or memory card.
For Dual zone an external monitor with is
required having its own acoustic system and
possibility of volume adjustment.
Press DUAL button to select between
C-DUAL (buttons perform operations for the
current mode of the front zone) or D-DUAL
(buttons perform DVD functions).
System setup
When you select SETTING mode, the menu
will be displayed, in which you can touch any
item to select corresponding setting page:
After selecting a menu page you can
navigate in the menu by pressing cursor
buttons on the RC and confirm your selection
by pressing ENTER button on the RC. Menu
subpages are selected by pressing
/
buttons on the RC. Or touch the items on the
