Pulldown Assembly Guide: Getting Started
3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fasteners
Quantity
Buttonhead cap screw (M8 x 15 mm)
1
Socket head cap screw (M12 x 35 mm)
16
Socket head cap screw (M5 x 20 mm)
2
Socket head cap screw (M5 x 12 mm)
4
Flat washer (9 mm internal diameter)
5
Set screw (M8 x 6 mm)
10
