Calf Raise Assembly Guide: Getting Started
3
Hardware Kit (not to scale)
The following pieces of hardware are provided on a shrink-wrapped card. Each part is labeled on the card for easy reference.
Table 1. Hardware kit contents
Fasteners
Quantity
Buttonhead cap screw (⁵₁₆-inch x 3¹₄-inch)
8
Socket head cap screw (M12 x 35 mm)
7
Flat washer (9 mm internal diameter)
9
Buttonhead cap screw (M8 x 15 mm)
1
Set screw (M8 x 6 mm)
2
Flat washer (13 mm internal diameter)
9
Socket head cap screw (M12 x 135 mm)
1
Nylon lock nut (M12)
1
